FTTH Cable Production
At Shanghai Weiye OFC Equipment, manufacturing steps are built around network requirements, combining brand fiber choices with disciplined test flows.
Fiber Selection & Brand Options
We align fiber draw tower to minimum bend radius, loss, and install environment. Options include OS1/OS2 and OM2–OM4 and G.652D and G.657.A1/A2 per ITU-T. Brand fibers such as Fujikura® and Corning® SMF-28e are offered to satisfy sourcing standards.
Strength member integration
Strength members employ FRP (dielectric) or galvanized steel wire. FRP is preferred where non-conductivity is necessary. Steel wire adds tensile strength for longer aerial spans and grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility and ease of handling, and PE for UV/moisture resistance outdoors. Tight process control of temperature and capstan ratios keeps line speed stable and dimensional tolerances.
| Member | FRP | Metallic Steel |
|---|---|---|
| Use case | Non-conductive runs | Aerial spans, high tensile |
| Key benefit | Lightweight, inert | Very high tensile strength |
| Installer note | Easier terminations | Requires grounding |
Testing & Verification
Inline geometry and concentricity checks operate in-line. Final optical tests confirm loss and reflectance. Each order includes a 100% test report and lab results from high-temperature, salt-spray, and vibration tests to confirm handling for drop terminations and field use.
Typical lead times are 4–5 days for < 100 km and 7–10 days for < 500 km. Lot records and FAI approvals support traceability and compliance for U.S. projects.
Our FTTH Drop Cable Types and Structures
Shanghai Weiye OFC Equipment provides a focused portfolio of FTTH drop designs that fit indoor risers and long aerial runs. Each option combines tested materials with field-termination geometry and stable optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It keeps bend loss low for simple routing in MDU corridors and hallways.
Self-supporting designs for aerial spans
Self-supporting FTTH drop designs use a support messenger to handle tension. Choose FRP (dielectric) for non-conductive runs or steel messenger when bonding/grounding and extra tensile strength are required.
Core Layouts and Strength Members
We provide dielectric and metallic strength member configurations to meet safety/EMI requirements. Central loose-tube and flat unitube types balance crush resistance and fiber secondary coating line for quick termination.
Indoor/outdoor jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor UV and moisture resilience. Each series is validated for mechanical and optical quality before shipment.
| Design | Application | Strength member | Sheath |
|---|---|---|---|
| Flat bow-type | Indoor risers, MDUs | FRP (dielectric) | LSZH |
| Self-supporting (aerial) | Aerial spans | FRP/Steel | PE |
| Central loose-tube | Higher fiber counts | Dielectric FRP | LSZH or PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH or PE |
Equipment Ensuring Quality and Throughput
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and boost throughput for drop patch preparation.
Our production line integrates automated machines that cut/strip drop cords to raise throughput and cut labor variability.
The CLX-BPO2 auto-stripping machine runs under PLC and photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Auto Cut & Strip Capabilities
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise reserved lengths. Pneumatic cylinder actuators provide quick, repeatable motion and low downtime.
PLC/photoelectric control for precision and repeatability
PLC logic and photoelectric sensors give exact positioning and closed-loop control. Inline checks update SPC charts so operators can correct trends before out-of-control conditions occur.
| Feature | Spec | Result |
|---|---|---|
| Machine | 1.5s cycle, auto-strip | ~20 terminals/minute throughput |
| Drive | Pneumatic cylinders | High speed and reliability |
| Material handling | LSZH/PVC; FRP/steel | Clean, accurate preps |
| Process control | PLC/photoelectric with in-line SPC | Stable quality, reduced rework |
- Automated waste ejection and ergonomic loading keep the line clean.
- Process control plans document calibration and key parameters.
- Integrated assets and trained operators help meet FTTH volume goals without compromising accuracy.
CLX-BPO2 Capabilities on Our Line
The CLX-BPO2 brings industrial-grade stripping and trimming to our line, cutting cycle time while maintaining consistent prep.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to raise output and standardize terminal quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control deliver exact detection and repeatable actuation. That control keeps strip and stub lengths within tight tolerances.
Cycle time and throughput
Typical operation speed is 1.5s per cycle. This converts to steady throughput under continuous line conditions.
Jacket Strip & Stub Lengths
The CLX-BPO2 strips LSZH and PVC jackets with an adjustable strip length from 17.5 to 35.0 mm. Reserved stubs are set between 7.0 and 11.0 mm to match common termination hardware.
Handling FRP and steel wire strength members
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Custom tooling are offered for non-standard cross-sections to preserve precision.
- Auto-eject scrap and sensor start cut idle time.
- Compact size (L40 × W18 × H18 cm), 110–220V, 50W, and 11 kg mass ease integration into workcells.
- Pneumatic cylinders and PLC/photoelectric control improve line reliability and lower maintenance interruptions.
| Spec | Value | Benefit |
|---|---|---|
| Cycle time | ~1.5 s (~20/min) | High throughput for production runs |
| Strip lengths (A) | 17.5–35.0 mm | Compatible with common connectors |
| Stub (B) | 7.0 to 11.0 mm | Meets strength and termination needs |
| Power & size | 110–220V, 50W; 40×18×18 cm | Easy integration into existing equipment |
Using this machine, Shanghai Weiye OFC Equipment standardizes prep so field teams get drop parts install-ready. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Tailored Specifications for Your Network
Shanghai Weiye OFC Equipment configures each build to fit your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1–4 core designs with single-mode or multimode fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D/G.657 variants to align with optics and connector plans.
We Pantone-match sheath colors for fast field ID and consistent asset tags.
Jackets, Legends & Branding
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom legends/logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard put-ups are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose flat bow-type or self-supporting and steel wire or FRP strength members to meet span and isolation needs.
| Option | Common choice | Benefit |
|---|---|---|
| Reel length | 1, 2, or 4 km | Less staging, easier reels |
| Sheath | LSZH, PE, PVC | Indoor/Outdoor fit |
| Structure | Bow-type / Self-supporting | Routing and span flexibility |
As a manufacturer, Shanghai Weiye aligns runs to your schedule and provides docs that detail final specs for easy on-site QA.
Quality, Test, and Docs
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
Environmental and Mechanical Tests
Our lab conducts high-temperature exposure, salt spray corrosion, and mechanical vibration to qualify materials/assemblies. These tests simulate field stresses for indoor/outdoor applications.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that logs attenuation, return loss, and geometry where applicable. Final inspection gates prevent nonconforming shipments before they leave the factory.
Audit Trail and Compliance
Lot/batch records link tests to reels/serials so audits and claims are easy to verify. Documentation uses standard customer templates to speed approvals and inbound inspection.
- In-line checks plus final inspection reduce field failures and cut warranty events.
- Quality packages include specifications confirmation and formatted test data for quick review.
- Continuous test trends drive preventive maintenance and improve long-term reliability.
| Test | Why | Outcome |
|---|---|---|
| High-temperature | Thermal stability | Pass at target temperature |
| Salt-fog | Corrosion resistance | Qualified for outdoor use |
| Vibration | Resistance to vibration | Improved field reliability |
Pricing and cost drivers for FTTH drop cable
Budgeting for a drop run begins with fiber/jacket selection and is refined by volume and customization.
Typical prices vary widely—from about $30 to $1,000 per unit—based on fiber grade, jacket chemistry (LSZH, PVC, PE), reel length, and structural design.
Primary Cost Inputs
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel strength elements raise material and labor input. Custom colors, logos, and print legends add setup and influence price for short runs.
Order length, volume, and customization impact on price
Longer reels and higher volume orders reduce unit cost. Short runs often include setup charges and higher unit prices.
- Changeovers and special cutters increase lead time and add cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Framework agreements and indexed pricing stabilize budgets over phases.
| Factor | Effect on price | Recommendation |
|---|---|---|
| Fiber grade | Large | Right-size spec to budget |
| Sheath material | Medium | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate where possible |
Logistics for the U.S.
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align staffing and sites. Predictable schedules reduce downtime and help control cost when a rollout is underway.
Scheduling & Capacity Planning
Typical production windows run 4–5 days for orders under 100 km and 7–10 days for < 500 km. We schedule line capacity to track your milestones and to maintain on-time delivery.
The service team issues production updates and tracking so installation teams can plan arrivals. For tight schedules, we hold contingency capacity to accelerate critical-path orders.
Minimum order quantity and why it matters
The MOQ is 1 km. This reflects line setup such as wire/die adjustments that use startup material and generate scrap.
We review your put-ups and staging to select reels to reduce waste/handling. Batch releases can balance inventory with frequent, smaller deliveries to job sites.
Installation Scenarios & Readiness
On-site conditions determine whether a self-supporting aerial, duct pull, or direct-buried run is the right choice for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment advises self-supporting designs with correct strength members to control sag and tension for long-term stability.
Duct installations perform best with low-friction jackets and crush-resistant builds so pulling does not damage fibers. PE jackets are common for underground and buried paths where moisture resistance is needed.
Direct-buried designs require proper depth control per local codes and moisture-resistant jackets to protect the fiber core long-term.
Indoor Distribution and ONT
Indoor riser/plenum routes prefer LSZH to meet flame and smoke rules. Flat drop profiles strip clean and present controlled strength stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning exposure, and hardware fit. Standardized prep from the production line shortens install time and reduces scrap.
| Deployment | Key feature | Installer note |
|---|---|---|
| Overhead | Self-supporting (steel/FRP) | Check tension and messenger hardware |
| Duct | Low-friction jacket, crush resistance | Use pull tape and proper lubricant |
| Direct-buried | PE jacket, moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor/outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.
After-sales service includes fast response, RCA, and corrective action. All products ship with full test reports and traceability to help QA acceptance.
- 24/7 availability for status and technical support.
- Warranty with free replacement if any quality problems are confirmed.
- Schedule coordination for urgent changes or acceleration requests.
- Configuration control so shipped items match agreed requirements every time.
| Area | Scope | Benefit |
|---|---|---|
| Engineering | Specs + pilots | Fewer field issues |
| QA/Testing | Lab + 100% reports | Traceable quality |
| After-sales | Fast replace + RCA | Lower downtime |
Final Thoughts
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We deliver customized FTTH drop solutions that pair material choices with validated manufacturing and lab testing. Every reel ships with a 100% test report and documented lab trials to support U.S. field acceptance.
A hardened production line, including CLX-BPO2 prep assets, reduces variability and shortens turnaround. Our equipment set standardize strip/stub lengths so installers see consistent results at turn-up.
From fiber selection through jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated support guides scheduling, logistics, and after-sales care so your deployment remains on plan.
Get in touch with Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with laboratory validation and responsive support.
